The polymer make-up system is designed to automatically dilute powder polymer to a specific concentration. This device is beneficial either to sludge dewatering, or to various wastewater treatment processes, such as e.g. DAF.
Polymer Make-up System – Powder
Polymer Make-up System – Powder
Save labor by fully automatic operation
Just refill the stock solution tank / the hopper with polymer, and the device will do the rest from measurement to dissolution.
Consistent concentration
The concentration of the diluted polymer Is kept consistent as the device automatically measures the stock solution and dilution water.
Interlocked operation with sludge dewatering press or another machine
The device keeps monitoring the dissolving tank and the stock solution tank / the hopper using sensors. When the level of the polymer is low or when supply of dilution water is inadequate, the device automatically stops and sends a warning signal to external equipment.
Specifications List
CS series
| Model | Max. dissolving capacity [L/h] | Hopper Capacity [L] | Dimensions [mm] | Total Power Consumption [kW] | Weight [kg] | |||
|---|---|---|---|---|---|---|---|---|
| L | W | H | Empty | Operation | ||||
| CS-600 | 600 | 40 | 1500 | 830 | 1700 | 0.9 | 180 | 980 |
| CS-1100 | 1100 | 60 | 1740 | 1120 | 1800 | 0.9 | 240 | 1580 |
| CS-1500 | 1500 | 60 | 2230 | 1110 | 1830 | 1.2 | 260 | 1940 |
| CS-1900 | 1900 | 60 | 2750 | 1060 | 1830 | 1,2 | 280 | 4350 |
| CS- 3000 | 3000 | 60 | 2980 | 1280 | 1990 | 1.5 | 350 | 3900 |
*Polymer dosing pump is not included within the scope of supply of this product. We will select the corresponding pump based on your requirement. Please consult us.
AMCON can offer polymer make-up system for a larger capacity. Please feel free to contact us for details.
